OEM#: L3510New OEM Original Outright
MOTOR 1 HP 1725 RPM 115/230V 56H TEFC by BALDOR
Your price:
$1,203.15 each
OEM#: L3510MOTOR 1 HP 1725 RPM 115/230V 56H TEFC by BALDOR
New OEM Original Outright
Your price:
$1,203.15 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: L3510 Key Specs
Item
MOTOR 1 HP 1725 RPM 115/230V 56H TEFC
OEM
BALDOR
OEM #
L3510
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
CC Number
CC031A
Country of Origin
USA
Duty
Continuous
Frame
56H
Full Load Amps
11.8/5.9
HP
1 hp
Hz
60
Includes
Conduit Box
Ins. Class
F
Length Less Shaft
11 in
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
Capacitor-Start
Motor Efficiency Group
Energy Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Rolled Steel
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1725
Nominal Efficiency
70 %
Number of Speeds
1
Overall Length
12 29/32 in
Phase
1
RPM Group
1701-1800
RPM Range
1701-1800
Shaft Diameter
5/8 in
Shaft Length
1-7/8 in
Standards
CSA, UL
Voltage
115/230
