OEM#: BC160New OEM Original Outright

DC CONTROL, DC SCR CONTROL, 230V, 3 HP, NEMA 4X by BALDOR

Your price:
$1,071.00 eachReady to ship
HomeBALDORBC160
DC CONTROL, DC SCR CONTROL, 230V, 3 HP, NEMA 4X by BALDOR
DC CONTROL, DC SCR CONTROL, 230V, 3 HP, NEMA 4X by BALDOR

OEM#: BC160
DC CONTROL, DC SCR CONTROL, 230V, 3 HP, NEMA 4X by BALDOR

New OEM Original Outright
Your price:
$1,071.00 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance DC Control, DC SCR CONTROL, 230V, 3 HP, NEMA 4X

Features:
  • Full wave SCR control with free wheeling diode (NEMA type K)
  • Field power supply allows use with shunt wound DC motors as well as permanent magnet motors
  • Adjustable accel, decel, current limit, IR comp, min and max speed
  • Current limit indicating LED
  • 5K speed pot for speed control
  • Anti-demag circuit protects PM motors and helps protect the SCR power bridge against direct shorts
  • Noise rejection circuit eliminates false starts and blown SCR's
  • UL and cUL recognized
Typical Applications:
Conveyors, mixers, packaging machinery and other applications requiring variable speed and constant torque.
Technical Specs
P/N: BC160 Key Specs
Item
DC CONTROL, DC SCR CONTROL, 230V, 3 HP, NEMA 4X
OEM
BALDOR
OEM #
BC160
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temperature Max
40
Ambient Temperature Min
0
Ce Approval
Approved
Cooling Type
CONVECTION
Country of Origin
USA
Csa Approval
Approved
Cul Aproval
Approved
Dc Tach Interface
N/A
Depth Inches
5
Dynamic/Regenerative Braking
NONE
Enclosure Material
NEMA 4X
Field Power Supply
N/A
Height Inches
9.5
Hi-Res Analog Input
N/A
Hp
3
Input Phase - Rated
1
Input Voltage
230
Isolated Encoder
N/A
Isolated Input
Optional
Master/Pulse/Follower
N/A
Number Of Axis
1
Operator Interface
POT
Pneumatic-In/Relay-Out
N/A
Resolver Input
N/A
Rs232
N/A
Rs422/Rs485
N/A
Type
ANALOG
Ul
Approved
Width Inches
5.9
Baldor-Reliance DC Control, DC SCR CONTROL, 230V, 3 HP, NEMA 4X

Features:
  • Full wave SCR control with free wheeling diode (NEMA type K)
  • Field power supply allows use with shunt wound DC motors as well as permanent magnet motors
  • Adjustable accel, decel, current limit, IR comp, min and max speed
  • Current limit indicating LED
  • 5K speed pot for speed control
  • Anti-demag circuit protects PM motors and helps protect the SCR power bridge against direct shorts
  • Noise rejection circuit eliminates false starts and blown SCR's
  • UL and cUL recognized
Typical Applications:
Conveyors, mixers, packaging machinery and other applications requiring variable speed and constant torque.
