OEM#: BWP20-12New OEM Original Outright

AREA SENSOR NPN PLASTIC 20MM 12 BEAM by Autonics

Your price:
$930.53 each
$935.18 Savings: $4.65 (0%)
Estimated to ship by 11/27 if ordered before 4:30 PM EST
HomeAutonicsbwp2012
AREA SENSOR NPN PLASTIC 20MM 12 BEAM by Autonics
AREA SENSOR NPN PLASTIC 20MM 12 BEAM by Autonics

OEM#: BWP20-12
AREA SENSOR NPN PLASTIC 20MM 12 BEAM by Autonics

New OEM Original Outright
Your price:
$930.53 each
$935.18 Savings: $4.65 (0%)
Estimated to ship by 11/27 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: BWP20-12 Key Specs
Item
AREA SENSOR NPN PLASTIC 20MM 12 BEAM
OEM
Autonics
OEM #
BWP20-12
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Beam Spacing
20 mm
Cable Connection
4 Bare Wires
Cable Length
3 m
Circuit Type
NPN Open Collector
Country of Origin
Republic of Korea
Current Consumption
80 mA
Depth
22.6 mm
Housing Material
Plastic
IP Rating
40
Includes
Emitter, Receiver and Instructions
Light Source
Infrared LED
Max Load Current
100 mA
Max Load Voltage
30V DC
Min Target Size
Opaque Material 30mm
Number of Beams
12
Operating Temperature Range
-20 to 60 Degrees C
Output Mode
Light-On
Overall Height
290 mm
Power Source
12 to 24V DC
Response Time
6 msec
Sensing Height
270 mm
Sensing Range
0.1 to 5m
Width
28.6 mm
