OEM#: BW20-40PNew OEM Original Outright

AREA SENSOR PNP METAL 20MM 40 BEAM by Autonics

Your price:
$3,803.65 each
$3,821.83 Savings: $18.18 (0%)
Estimated to ship by 12/27 if ordered before 4:30 PM EST
HomeAutonicsbw2040p
AREA SENSOR PNP METAL 20MM 40 BEAM by Autonics
AREA SENSOR PNP METAL 20MM 40 BEAM by Autonics

OEM#: BW20-40P
AREA SENSOR PNP METAL 20MM 40 BEAM by Autonics

New OEM Original Outright
Your price:
$3,803.65 each
$3,821.83 Savings: $18.18 (0%)
Estimated to ship by 12/27 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: BW20-40P Key Specs
Item
AREA SENSOR PNP METAL 20MM 40 BEAM
OEM
Autonics
OEM #
BW20-40P
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Beam Spacing
20 mm
Cable Connection
4 Pin M12
Cable Length
300 mm
Circuit Type
PNP Open Collector
Country of Origin
Republic of Korea
Current Consumption
80 mA
Depth
22.6 mm
Housing Material
Aluminum
IP Rating
65
Includes
Emitter, Receiver and Instructions
Light Source
Infrared LED
Max Load Current
100 mA
Max Load Voltage
30V DC
Min Target Size
Opaque Material 30mm
Number of Beams
40
Operating Temperature Range
-20 to 60 Degrees C
Output Mode
Light-On
Overall Height
820 mm
Power Source
12 to 24V DC
Response Time
12 msec
Sensing Height
800 mm
Sensing Range
0.1 to 7m
Width
28.6 mm
