P/N: GC517F0242CD3000#G Key Specs
Item
PRESSURE TRANSDUCER WITH DISPLAY 3000PSI
Condition
New OEM Original
Accuracy - Transmitter
+/-0.25% Full Scale
Connection Location - Transmitter
Bottom
Diameter - Transmitter
2.56 in
Display - Transmitter
3-1/2 Digit Backlit LCD
Electrical Connections - Transmitter
Terminal Board
Loop Resistance
Dependent on Loop Supply Voltage
Manufacturers Warranty Length
1 yr
Max Pressure (PSI)
4,500 psi
Operating Temperature - Transmitter
14 Degrees to 140 Degrees F
Output - Transmitter
4 to 20mA DC
Overall Depth - Transmitter
3.62 in
Overall Height - Transmitter
3.35 in
Power Required - Transmitters
12 to 32V DC
Process Connection Size - Transmitter
1/4 in
Process Connection Type - Transmitter
FNPT
Range Units - Transmitter
psi
Range Values - Transmitter
0 to 3000
Shape - Transmitter
Irregular
Transmitter Type
Pressure Transmitter
Wetted Materials - Transmitters
316 Stainless Steel
Wiring Entry - Transmitter
1/2 in FNPT
