OEM#: 32J020New OEM Original Outright

MANUAL TWO-WAY BALL VALVE, 2 IN, BRASS, STRAIGHT, MIP X FIP, FULL PORT BALL PORT by Approved Vendor

Your price:
$211.28 eachEstimated to ship by 12/06 if ordered before 4:30 PM EST
HomeApproved Vendorgra32j020
MANUAL TWO-WAY BALL VALVE, 2 IN, BRASS, STRAIGHT, MIP X FIP, FULL PORT BALL PORT by Approved Vendor
MANUAL TWO-WAY BALL VALVE, 2 IN, BRASS, STRAIGHT, MIP X FIP, FULL PORT BALL PORT by Approved Vendor

OEM#: 32J020
MANUAL TWO-WAY BALL VALVE, 2 IN, BRASS, STRAIGHT, MIP X FIP, FULL PORT BALL PORT by Approved Vendor

New OEM Original Outright
Your price:
$211.28 each
Estimated to ship by 12/06 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: 32J020 Key Specs
Item
MANUAL TWO-WAY BALL VALVE, 2 IN, BRASS, STRAIGHT, MIP X FIP, FULL PORT BALL PORT
OEM
Approved Vendor
OEM #
32J020
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
3-A Compliance
Not Rated
Ball Material
304 Stainless Steel
Ball Port Style
Full Port
Body Material
Brass
Coefficient of Volume (Cv)
144.194
Connection Gender - Side 1
Male
Connection Gender - Side 2
Female
Connection Size
2 in x 2 in
Connection Size - Side 1
2 in
Connection Size - Side 2
2 in
Connection Type - Side 1
IPS
Connection Type - Side 2
IPS
Country of Origin
China
For Media
Combustible Gases, Steam, Water
Handle
Lever
Handle Color
Red
Handle Material
Steel
Manufacturer Warranty
1 yr
Max. Pressure (CWP)
600 psi
Max. Pressure (Combustible Gas)
Not Rated
Max. Pressure (Steam)
600 psi
Media Temp. Range
-20 °F to 300 °F
NSF Certifications for Food and Drinking Water
NSF 61
Nominal Valve Size
2 in
Overall Length
8.17 in
Seal Material
PTFE
Seat Material
PTFE
Standards
ANSI Z21.15/CGA 9.1, ASME B16.44, FM 1140, IAPMO/ANSI Z1157, NSF/ANSI 372, YQNZ, YRBX
Stem Material
Brass
Stem Type
Blowout Resistant
Vacuum Service Rating
-29.92 in Hg
Valve Body Style
Straight
Valve Construction
Two-Piece
Valve Series
7700MF
Vented Ball Valve
Non-Vented
