OEM#: HX11/16New OEM Original Outright

SPLIT TAPER BUSHING, H, 11/16 IN BORE DIA, 2 IN BOLT CIRCLE DIA, 2.5 IN OVERALL DIA by Approved Vendor

Your price:
$19.88 eachEstimated to ship by 04/10 if ordered before 1:30 PM EST
HomeApproved Vendorhx1116813c81
SPLIT TAPER BUSHING, H, 11/16 IN BORE DIA, 2 IN BOLT CIRCLE DIA, 2.5 IN OVERALL DIA by Approved Vendor
SPLIT TAPER BUSHING, H, 11/16 IN BORE DIA, 2 IN BOLT CIRCLE DIA, 2.5 IN OVERALL DIA by Approved Vendor

OEM#: HX11/16
SPLIT TAPER BUSHING, H, 11/16 IN BORE DIA, 2 IN BOLT CIRCLE DIA, 2.5 IN OVERALL DIA by Approved Vendor

New OEM Original Outright
Your price:
$19.88 each
Estimated to ship by 04/10 if ordered before 1:30 PM EST
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: HX11/16 Key Specs
Item
SPLIT TAPER BUSHING, H, 11/16 IN BORE DIA, 2 IN BOLT CIRCLE DIA, 2.5 IN OVERALL DIA
OEM
Approved Vendor
OEM #
HX11/16
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bolt Circle Diameter
2 in
Bore Bushing Series
H
Bore Diameter
11/16 in
Bore System of Measurement
Inch
Bushing Type
Split Taper
Country of Origin
China
Fastener Tightening Torque
95 in-lb
Flange Thickness
1/4 in
Flange Type
Solid
For Shaft Type
Keyed
Includes
(2) Cap Screws
Keyway Depth
3/32 in
Keyway Width
3/16 in
Large Barrel Diameter
1.625 in
Length Less Flange
1 in
Material
Steel
Overall Diameter
2.5 in
Overall Length
1.25 in
Small Barrel Diameter
1.57 in
Taper
3/4 in Per ft
