OEM#: 111797New OEM Original Outright

REPEAT CYCLE TIMER, 0-60 SEC, DPDT - 120 VAC by Advance Controls, Inc.

Your price:
$104.21 eachEstimated to ship by 12/02 if ordered before 10:30 AM EST
HomeAdvance Controls, Inc.111797
REPEAT CYCLE TIMER, 0-60 SEC, DPDT - 120 VAC by Advance Controls, Inc.
REPEAT CYCLE TIMER, 0-60 SEC, DPDT - 120 VAC by Advance Controls, Inc.

OEM#: 111797
REPEAT CYCLE TIMER, 0-60 SEC, DPDT - 120 VAC by Advance Controls, Inc.

New OEM Original Outright
Your price:
$104.21 each
Estimated to ship by 12/02 if ordered before 10:30 AM EST
Asset Information
ADD TO LIST
Product Overview

Repeat Cycle Timer, 0-60 sec, DPDT - 120 VAC

The ACI Twin Setting Repeat Cycle Timer features two timers in one case, acting as a continuously functioning repeat cycle timer. The twin setting repeat cycle timer allows independent setting of both "on" and "off" time. This provides the needed flexibility required for many timing applications. When power is applied to the timer coil, the lead timer immediately begins its time delay. Once the lead timer's delay is reached, the relay contacts transfer and remain transferred until the lag timer's delay setting is reached. The relay contacts are released, both timers are reset and the timing cycle automatically begins. Both the lead and the lag timer can be set at any point from zero to full scale by adjusting the twin knobs. Any pattern of relay contacts "ON" and "OFF" can be achieved.

Technical Specs
P/N: 111797 Key Specs
Item
REPEAT CYCLE TIMER, 0-60 SEC, DPDT - 120 VAC
OEM
Advance Controls, Inc.
OEM #
111797
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
1 Phase 120Vac
±10%
1 Phase 230Vac
±1%
3 Phase 230Vac
0.1 Sec. Max
Certifications
UL Listed E158650 RU CE
Coil Volts
120 VAC
Country of Origin
Taiwan
Input Frequency
250,000 Cycles
Mounting
8 Pin Octal Socket
Operating Temperature
+15° - +120° F ( - 10 - +50° C)
Weight Lbs.
.4 lbs

Repeat Cycle Timer, 0-60 sec, DPDT - 120 VAC

The ACI Twin Setting Repeat Cycle Timer features two timers in one case, acting as a continuously functioning repeat cycle timer. The twin setting repeat cycle timer allows independent setting of both "on" and "off" time. This provides the needed flexibility required for many timing applications. When power is applied to the timer coil, the lead timer immediately begins its time delay. Once the lead timer's delay is reached, the relay contacts transfer and remain transferred until the lag timer's delay setting is reached. The relay contacts are released, both timers are reset and the timing cycle automatically begins. Both the lead and the lag timer can be set at any point from zero to full scale by adjusting the twin knobs. Any pattern of relay contacts "ON" and "OFF" can be achieved.
